PN6.4MPa
公称通径DN |
50 |
80 |
100 |
150 |
200 |
250 |
300 |
350 |
400 |
450 |
500 |
L |
RF |
292 |
356 |
406 |
495 |
597 |
673 |
762 |
826 |
902 |
978 |
1054 |
BW |
292 |
356 |
406 |
495 |
597 |
673 |
762 |
826 |
902 |
978 |
1054 |
HI |
110 |
120 |
140 |
185 |
220 |
270 |
310 |
345 |
410 |
440 |
480 |
H |
180 |
200 |
210 |
290 |
320 |
380 |
430 |
450 |
550 |
580 |
630 |
w |
400 |
700 |
850 |
600 |
600 |
600 |
800 |
800 |
800 |
800 |
800 |
E |
|
|
|
116 |
116 |
116 |
171 |
171 |
257 |
257 |
257 |
F |
|
|
|
3S0 |
350 |
350 |
420 |
420 |
500 |
500 |
500 |
PN16.0MPa
公称通径DN |
50 |
80 |
100 |
150 |
200 |
250 |
300 |
350 |
400 |
450 |
500 |
L |
RF |
292 |
356 |
432 |
559 |
660 |
787 |
838 |
889 |
991 |
1092 |
1194 |
BW |
295 |
359 |
435 |
562 |
664 |
791 |
841 |
892 |
994 |
1095 |
1200 |
RTJ |
292 |
356 |
432 |
559 |
660 |
787 |
838 |
889 |
991 |
1092 |
1194 |
Hl |
110 |
120 |
140 |
185 |
220 |
270 |
310 |
345 |
410 |
440 |
480 |
H |
180 |
200 |
210 |
290 |
320 |
380 |
430 |
450 |
550 |
580 |
630 |
W |
400 |
850 |
1000 |
600 |
600 |
800 |
800 |
800 |
800 |
800 |
800 |
E |
|
|
|
116 |
116 |
171 |
171 |
171 |
150 |
83 |
123 |
F |
|
|
|
350 |
350 |
500 |
420 |
420 |
580 |
650 |
735 |
PN16.0MPa
公称通径DN |
50 |
80 |
100 |
150 |
200 |
250 |
300 |
350 |
400 |
450 |
500 |
L |
RF/BW |
368 |
381 |
457 |
610 |
737 |
838 |
965 |
1029 |
1130 |
1219 |
1334 |
RTJ |
371 |
384 |
460 |
613 |
740 |
841 |
968 |
1038 |
1140 |
1219 |
1334 |
H1 |
135 |
158 |
190 |
200 |
250 |
285 |
350 |
400 |
480 |
530 |
580 |
H |
190 |
200 |
230 |
300 |
375 |
420 |
460 |
530 |
600 |
640 |
700 |
W |
600 |
600 |
600 |
600 |
800 |
800 |
800 |
800 |
800 |
800 |
800 |
E |
116 |
116 |
116 |
171 |
171 |
83 |
83 |
123 |
123 |
180 |
180 |
F |
350 |
350 |
350 |
420 |
420 |
650 |
650 |
735 |
735 |
735 |
735 |
PN16.0MPa
公称通径DN |
50 |
80 |
100 |
150 |
200 |
256 |
300 |
L |
RF/BW |
368 |
470 |
546 |
705 |
832 |
991 |
1130 |
RTJ |
371 |
473 |
549 |
711 |
841 |
1000 |
1146 |
H1 |
140 |
160 |
200 |
210 |
260 |
300 |
365 |
H |
200 |
220 |
250 |
320 |
400 |
450 |
490 |
W |
600 |
600 |
600 |
600 |
800 |
800 |
800 |
E |
116 |
116 |
171 |
171 |
83 |
83 |
123 |
F |
350 |
350 |
420 |
420 |
650 |
650 |
735 |
